【Capacity】30-400 T/H
【Feeding Size】＜300mm
【Screen material】PU, manganese, or stainless steel, 1 layer, 2 layers.
【Types】Fixed type and portable type
【Application】Suitable for effectively washing and sieving ore material which contains sticky clay and mud, and prevents clogging in Gold dredger, quartz mine, limonite ore, nonferrous ore, construction use sand and gravel washing, etc.
【Service】Trommel Scrubber design, mineral separation test, mineral processing process design, on-site installation or remote installation.
The trommel scrubber, commonly referred to as a rotary screen ore washer or cylinder screen washer, is a versatile piece of hydraulic equipment designed for cleaning soil and sticky mud. This innovative machine performs dual functions: it effectively cleans raw materials while also screening them by particle size. The trommel scrubber not only provides preliminary cleaning of materials but also efficiently sieves them, enhancing the overall processing of gold recovery operations.
【Capacity】0-130 T/H
【Feeding Size】0-6mm
【Type】Intermittent Discharge Centrifugal Concentrator, Automatic Continuous Discharge Centrifugal Concentrator,Vertical Automatic Discharging Centrifuge and Vertical Manual Discharging Centrifuge.
【Application】Suitable for the separation and recovery of fine-grained ferrous, non-ferrous, precious, and rare metal minerals, as well as the monomeric gold recovery from polymetallic ores. Applicable minerals include alluvial gold/placer gold, vein gold ore, magnetite, hematite, specularite, tin ore, lead-zinc ore, gold ore, and barite. It can also be used for recovering fine metal minerals from various mine tailings.
【Service】Centrifugal Concentrator design, mineral separation test, mineral processing design, on-site installation or remote installation.
The centrifugal concentrator is a modern gravity-based separation device that uses centrifugal force to separate minerals. It is primarily used for processing gold, silver, lead, and zinc ores by efficiently separating valuable heavy minerals from tailing.
It is energy-efficient, environmentally friendly, and highly automated. This device is widely applied in mining, metallurgy, and chemical industries, especially for gold extraction in small mining operations.
【Capacity】 0-2T/H
【Feeding Size】 0.074-2 mm
【Type】Coarse sand (2~0.5mm), fine sand (0.5~0.074mm), slime deck(-0.074mm)
6-s shaking table, RP4 shaking table;
Single-layer shaker and multi-layer shaker;
Industrial shaker table, mini gold shaker table, lab shaker table, portable shaker table.
【Application】The gold shaking table is a highly effective gravity separator designed to separate various precious metals, non-ferrous metals and rare metal ores, including gold, tin, tungsten, lead, manganese, tantalum, and chrome ore, coal, titanium ore, etc.,.
【Service】Shaking table design, mineral separation test, mineral processing design, on-site installation or remote installation.
The shaking tables, also known as gold shakers or gold separation tables, are vital tools for fine gold recovery in gold shaker wash plants and alluvial gold mining operations. These tables effectively separate concentrates, medium concentrates, and tailing based on material density and grain size,known for its efficiency, simplicity, and environmentally friendly nature.
The Gold shaking table is a widely used gravity separation equipment, mainly applied in the concentration of gold, silver, tungsten, tin, niobium, tantalum, and other metallic ores. It works by using the combined action of gravity, friction, and water flow to separate minerals based on their density, achieving a layered effect and sorting them along different paths.
The 6-S shaking table is an indispensable piece of gravity separation equipment in the mining industry, known for its efficiency, simplicity, and environmentally friendly nature.
Our gold mining shaking tables can be used independently or integrated with other ore dressing equipment, including jig machine, centrifugal concentrator, sluice box, flotation equipment, magnetic drum separators, and spiral classifiers. Enhance your gold recovery process by utilizing our versatile shaking tables today!
【Capacity】1-30 T/H
【Feeding Size】<30 mm
【Type】Wet Jigger, Dry Jigger；Eccentric Jig Concentrator（Plunger& Diaphragm), Hydraulic Jigger, Movable Sieve Jigger, Air Pulsating Jigger, Trapezoid Jigger.
【Application】The jig concentrator is a highly efficient gravity separator designed to separate coarse grain ore in various applications, like the separation and extraction of alluvial gold/place gold mining, rock gold, iron, manganese, tin, tungsten, conltan, diamonds, barite, , fluorite, and garnet.
【Service】Jig Concentrator design, mineral separation test, mineral processing design, on-site installation or remote installation.
The Jigger Concentrator is an advanced mineral processing equipment designed to separate valuable minerals from gangue through gravity concentration. Utilizing a unique wave motion, this machine optimizes the separation process, making it an essential tool in the mining and mineral extraction industry.
Before using the jig concentrator, materials are fed automatically via a belt conveyor, slurry pump, or gravity flow, utilizing height differences for efficient processing. After the jig concentrator, gold concentrates are directed to the gold shaking table for further refinement, while tailings are sent to the sluice box for effective separation. Enhance your gold recovery operations with our streamlined jig saw machine process!
【Capacity】0-35m³/h
【Feeding Size】<20mm
【Application】The Vibrating Gold Sluice is designed for placer gold processing, including alluvial gold concentration, eluvial deposits processing, tailings reprocessing and small-scale mining.
【Service】Vibrating Gold Sluice Box design, mineral separation test, mineral processing design, on-site installation or remote installation.
The Vibrating Gold Sluice is an innovative gold recovery device optimized for placer deposits. Its patented rubber deck + crank-link mechanism generates 2-4Hz vertical pulsations, combining the high concentration ratio of traditional sluices (tens to hundreds times higher than jigs) with anti-blinding performance.
During operation, gold particles are continuously agitated by the pulsating deck for efficient separation. Though with lower concentrate yield, it achieves 20-30% higher recovery than fixed Carpet Sluice Box. Ideal for small/medium placer mines and mill tailings reprocessing, featuring simple structure, low power consumption, and minimal maintenance.
