Mechanical Flotation Cell for Cu-Au Ore Processing

【Capacity】0.2-38m³/min
【Effective】1-38m³
【Diameter of Impeller】340-1050mm
【Type】XCF&KYF flotation machine, BF Flotation Machine, SF Flotation Machine,Air Flotation Machine,Mechanical stirring flotation machine,
【Application】The flotation machine is widely used in enrichment for non-ferrous metals, black metals and non-metals in medium and big flotation factories for the roughing and scavenging concentration.Suitable for mineral processing plant for copper, lead, zinc, nickel, molybdenum, gold and other non-ferrous minerals for material selection, but also can be used for sorting ferrous metals (iron) and non-metallic (coal, fluorspar, talc, quartz sand) .
【Service】Flotation Machine design, mineral separation test, mineral processing process design, on-site installation or remote installation.
The XCF and KYF models are advanced aeration flotation machines designed for efficiency. With a smaller impeller diameter, they reduce peripheral speed and save 30%-50% on power consumption. Equipped with an air distributor, these machines ensure even air dispersion.

The U-shaped tank minimizes sand settlement, while the innovative impeller design extends the lifespan of both the impeller and stator. While the KYF model has low power consumption and cannot self-suction slurry, the XCF model can automatically draw in slurry and is more power-intensive. Together, these models form an effective system—XCF as the suction tank and KYF as the direct tank—capable of horizontal arrangement without the need for a foam pump. Optimize your operations with this powerful combination!
